T24 Wireless Base Stations

The T24 radio telemetry range is currently supported by four base stations, which in conjunction with the T24-tool kit can be used to configure all the devices within the range. Devices can listen for and transmit data packages to any device, therefore making control and group measurement very simple.

T24-BSi
The T24-BSi is one of a range of base stations that are required for configuration and calibration of the T24 modular telemetry system. Base stations can also be used for data collection systems by making available the T24 wireless transmitter data over the industrial interfaces.

The data sent by transmitter modules can be utilised by multiple receivers such as displays, handheld readers, analogue outputs, relay modules and computer interfaces. Receivers support common industrial power supplies and are available in robust IP rated enclosures with internal antennas optimised to give outstanding coverage.

The T24-BSi supports USB, RS232 and RS485 connectivity. On Windows PCs the free T24 Toolkit is used to configure and calibrate the T24 modular telemetry system while the free T24 logging and visualisation software allows monitoring and data collection.

T24-BSu, T24-BSue & T24-BSd
The T24-BSu, T24-BSue and T24-BSd are all simple USB devices. They draw power from the USB bus and therefore no further components are required to configure and control remote devices from a PC. All are supported by the T24-toolkit and T24 logging software allowing customers to develop their own custom software for their applications. The T24-BSue has an extended range of up to 800m (2,600ft), and the T24-BSd is a smaller portable device designed for laptops and tablets.
