STA-9 Stainless Steel S Type Tension & Compression Load Cell
The STA-9 series load cell is ideal for measuring both tensile and compressive forces. The standard metric threads at each end of the load cell are designed to accept standard spherical seating rod-end bearings. The STA-7 is suitable for many applications where a tension and compression load cell is required, for high accuracy measurements.
Manufactured from fully welded and hermetically sealed stainless steel, the STA-9 is suitable for many applications where high accuracy tension and compression load cell are required. Applications such as vessel weighing, material test machines and dynamometers are a few examples.
The STA-9 series can be supplied on it’s own or combined with our extensive range of instrumentation to provide a complete load monitoring system.
- Stainless steel fully welded construction
- Environmentally sealed to IP68
- High accuracy
- Ratings from 250kg to 10te
- Excellent long-term stability
- Vessel weighing
- Hanging scales
- Multi-point structural weighing
- Material/tensile test machines
- General force measurement
